BT-50: The New Milestone for a Worry-Free, Walk-Away Laboratory Workflow

The BT-50 barcode terminal revolutionizes the laboratory haematology workflow, providing a worry-free, walk-away experience by automating tasks traditionally performed manually by lab staff. The module is equipped with cooling unit for storing XN Check vials and storage compartment for CellClean Auto vials.

Comprehensive On-Board Management of XN Check and CellClean Auto Vials and Waste Management:
Efficiently manages storage and waste of XN Check and Cellclean Auto vials, ensuring smooth operation while maintaining a clean and organized workspace.

Scheduled and Measurement-Based Cleaning:
Automatically cleans analysers based on the number of measurements or a predefined schedule, ensuring consistent performance and reliability.

Integrated Touchscreen Interface:
The BT-50 is easily operated via its intuitive touchscreen, managing scheduled start-up, automated XN Check measurements, and the cleaning of Sysmex analysers.

Flexible Automated Shutdown:
Offers the ability to shut down the entire automation line or individual modules, conserving resources and optimizing efficiency.

Ease of Mind for Operators:
Reduces manual cleaning tasks, allowing operators to focus on more critical activities.

BT-50: Barcode terminal with added innovative functionalities – for XR-9000 & XN-9100 automation lines

  • Scheduled system start-up and automated QC handling eliminates waste in the process
  • Reduces manual efforts for quality control by automating storage and preparation of XN Check
  • Integrated cooler unit for XN Check and storage compartment for Cellclean Auto
  • Flexible, automated shutdown and cleaning with Cellclean Auto
  • Enables a higher level of automation to alleviate staff shortages

BT-50: Much More Than a Barcode Terminal

A Walk-Away Concept in Haematology

  • Automated Start-Up: The auto start-up process of the XR-9000/XN-9100 automation line can be started 30 minutes before the specified time. QC analysis can then be initiated automatically after the system starts.
  • Automated QC Handling: With the XN Check Controls on board the BT-50’s integrated cooler unit, the lab can schedule an automated QC measurement in the analytical modules. Should the remaining tests in a vial are insufficient, a second vial is automatically taken from the cooler. If no second vial is available, an alert is triggered.
  • Automated Cleaning: Autocleaning of the analytical units is possible with the onboard CellClean Auto in the BT-50. Cleaning can be flexibly scheduled at any date, time and on specific XR/XN module. Additional cleaning cycles outside of the set schedule or based on the number of measurements may also be automatically triggered.
  • Automated Shutdown: This function of the BT-50 is highly flexible with an option of shutting down the whole automation line (XR-9000/ XN-9100) or selected Sysmex analyser after cleaning. A shutdown of the BT-50 itself is also possible.
Applicable model
  • XR-9000 with up to 9 XR modules in the same line
Throughput
  • 1,000 tests/h or 100 racks/h
Main features
  • Integrated barcode terminal and start yard
  • Cooling and incubating of up to 9 XN Check vials for scheduled QC
  • Automated shutdown/cleaning with storage capacity for up to 40 Cellclean Auto vials
Temperature of the cooler unit
  • 2–8°C
Waste bin capacity
  • 200 vials
null

Sysmex XR-Series Brochure

Download »

null

Sysmex BT-50 PFS

Download »

Features & Benefits

BT-50: Much More Than a Barcode Terminal

A Walk-Away Concept in Haematology

  • Automated Start-Up: The auto start-up process of the XR-9000/XN-9100 automation line can be started 30 minutes before the specified time. QC analysis can then be initiated automatically after the system starts.
  • Automated QC Handling: With the XN Check Controls on board the BT-50’s integrated cooler unit, the lab can schedule an automated QC measurement in the analytical modules. Should the remaining tests in a vial are insufficient, a second vial is automatically taken from the cooler. If no second vial is available, an alert is triggered.
  • Automated Cleaning: Autocleaning of the analytical units is possible with the onboard CellClean Auto in the BT-50. Cleaning can be flexibly scheduled at any date, time and on specific XR/XN module. Additional cleaning cycles outside of the set schedule or based on the number of measurements may also be automatically triggered.
  • Automated Shutdown: This function of the BT-50 is highly flexible with an option of shutting down the whole automation line (XR-9000/ XN-9100) or selected Sysmex analyser after cleaning. A shutdown of the BT-50 itself is also possible.
Specifications
Applicable model
  • XR-9000 with up to 9 XR modules in the same line
Throughput
  • 1,000 tests/h or 100 racks/h
Main features
  • Integrated barcode terminal and start yard
  • Cooling and incubating of up to 9 XN Check vials for scheduled QC
  • Automated shutdown/cleaning with storage capacity for up to 40 Cellclean Auto vials
Temperature of the cooler unit
  • 2–8°C
Waste bin capacity
  • 200 vials
