XN-330 is a fully automated compact 6-part differential haematology analyser. The XN-330 offers single sample analysis in open mode. It has a fully integrated IPU (information-processing unit) including an LCD colour touchscreen that makes it easy to operate.
XN-330
Compact 6-part differential haematology analyser
Throughput of 60 samples per hour
Single sample analysis in open mode
Fully integrated IPU including LCD colour touchscreen
Only 25 µL aspiration volume in whole blood mode
Best-in-class diagnostics tailored to small and mid-sized laboratories
The XN-330 offers single sample analysis in open mode. It has a fully integrated IPU (information-processing unit) including an LCD colour touchscreen – so you do not need a separate computer to operate the analyser. It incorporates the proven Sysmex technologies of fluorescence flow cytometry, hydrodynamic focussing and our cyanide-free SLS method for determining haemoglobin
| Dimensions / weights |
|
| Throughput |
|
| Aspiration volume |
|
| Analysis parameters |
|
| Measurement principles |
|
| Data storage capacities |
|
| User maintenance |
|
- Features & Benefits
-
The XN-330 offers single sample analysis in open mode. It has a fully integrated IPU (information-processing unit) including an LCD colour touchscreen – so you do not need a separate computer to operate the analyser. It incorporates the proven Sysmex technologies of fluorescence flow cytometry, hydrodynamic focussing and our cyanide-free SLS method for determining haemoglobin
- Specifications
-
Dimensions / weights - W x H x D [mm / kg]
- XN-350: 450 x 510 x 460 / approx. 35 kg
Throughput - CBC: up to 60 samples/hour
- CBC + DIFF: up to 60 samples/hour
Aspiration volume - 25 µL in WB,
- 70 µL in PD
Analysis parameters - Whole Blood
WBC, RBC, HGB, HCT, MCV, MCH, MCHC, PLT, RDW-SD, RDW-CV, PDW, MPV, P-LCR, PCT, NEUT#, LYMPH#, MONO#, EO#, BASO#, NEUT%, LYMPH%, MONO%, EO%, BASO%, IG#, IG%
Measurement principles - WBC DIFF/RET: Fluorescence Flow Cytometry
- WBC: Flow Cytometry
- RBC/PLT: DC Impedance method with hydrodynamic focusing
- HGB: Cyanide-free SLS method
Data storage capacities - Results: 100,000 samples
- Patient information: 10,000 records
- Calibration history: 20 times/ module
- QC files: 99 files including XbarM
- QC plots: 300 plots / file
User maintenance - Daily shutdown
- Weekly cleaning sequence with Cellclean or Cellclean Auto
